Wheels and Axles
| Item | Weight Per piece, kg | Wheel tread dia, mm | Axle load(tonnes) |
|---|---|---|---|
| 16.25T AC Coaching Wheel Set | 1092 | 915 | 16.25 |
| 16.25T BG Coach Wheel | 384 | 920 | |
| 16.25T Loose Axle | 378 | 16.25 | |
| Diesel Loco Wheel | 528 | 1097 | |
| Loco Wheel ‘S’ shaped | 528 | 1097 | |
| MG Loco Wheel | 421 | 970 | 16.25 |
| Item | Weight Per piece (tonnes) | Wheel tread dia (mm) | Specification | Application |
|---|---|---|---|---|
| Coach Wheels | ||||
| BG Coach | 0.394 | 920 | R-19/93 | For Use in Passenger Coaches |
| EMU | 0.423 | 955 | ||
| Kolkata Metro | 0.342 | 780 | ||
| Narrow Gauge | 0.144 | 513 | ||
| LHB | 0.326 | 918 | ||
| Loco Wheels | ||||
| BG Loco | 0.53 | 1098 | R-34/15 | For use in Locomotives |
| SP Loco | 0.53 | 1096 | ||
| MG Loco | 0.421 | 970 | ||
| WAG 9 Loco | 0.554 | 1092 | ||
| WAP 5 Loco | 0.554 | 1092 | ||
| Others | ||||
| NTPC Wheel | 0.424 | 915 | R-19/93 | Merry Go-round |
| Axles | ||||
| 16.25T S/F Axle | 0.378 | R-16/95 | Passenger Coaches | |
